Architectural Specifications

Super Stud Building Products’ Architectural Specifications

Including Super Stud Building Products in your architectural specification ensures that your intended specs will be utilized by contractors in the field. Super Stud Building Product’s architectural specifications reduce change orders and unwanted costs associated with substitutions and additional approval processes.

All links below are to editable Microsoft Word® documents, ready for insertion directly into contract documents. Although Super Stud products are the basis of design, these are NOT closed specifications, and include other manufacturers of similar products. Super Stud Building Products is listed as the premiere manufacturer for Cold-Formed Metal Framing Systems for Division 5 and Division 9 Specification Sections.


Division 5: Structural Metal Framing (Specification section 05 40 00) 054000Cold-FormedMetalFraming

Super Stud is your full service source for structural cold-formed steel (CFS) products and accessories, including studs, tracks, clip angles, connectors, bridging, slip connectors, and other accessories.

Microsoft WordClick here for Specification section 05 40 00, ready for contract documents

Division 9: Nonstructural Metal Framing (Specification section 09 22 16) 092216NonstructuralMetalFraming

Nonstructural products include The EDGE™ interior studs, shaft wall studs, ceiling joists and tracks, clips, connectors, and a full line of both steel and vinyl accessories for gypsum construction. Using Super Stud specifications will ensure quality products and accessories for your structure: with true Galvanized metallic coating for corrosion protection (no “EQ” coatings), and 3rd party code compliance certification through Home Innovation Research Labs, Inc.

Microsoft WordClick here for Specification section 09 22 16, ready for contract documents

Safety Specification for Division 9 (section 09 22 16) 092216NonstructuralMetalFraming

For an added level of safety, Super Stud provides The EDGE™ products, where over 90% of sharp edges on framing members are covered or hemmed for added strength and safety. The specification below has added verbiage (section 2.2.A.2 for members and section 3.4.A for installation) requiring a safety edge on thinner framing members.

Microsoft WordClick here for Safety Specification section 09 22 16, ready for contract documents


Arcat

Complete Division 5 & Division 9 Architectural Specifications

The Super Stud Building Products specifications for Cold-Formed Metal Framing available on ARCAT are complete CSI 3-part and Canadian CSC architectural specs that can easily be downloaded, customized for your residential or commercial project, and included in your master spec for future use.


For engineering and architectural support, shop drawings and architectural specification inquires, contact our Technical Engineering Team at phone (732)-662-6200or email This email address is being protected from spambots. You need JavaScript enabled to view it.

For engineering and architectural support, shop drawings and architectural specification inquires, contact our Technical Engineering Team at phone (732)-662-6200or email This email address is being protected from spambots. You need JavaScript enabled to view it.

Home Innovation Research Labs

3rd Party Certifications

Home Innovation Research Labs, Inc., formerly the National Association of Home Builders (NAHB) Research Center, has been evaluating and certifying building products for over 25 years. Their staff has been instrumental in the development of code-referenced standards for cold-formed steel (CFS), and their expertise is recognized across the North American construction industry. Home Innovation’s certification provides confidence that certified products meet the requirements of the 2012 International Building Code (IBC). These requirements include material properties, dimensional tolerances, and labeling as detailed in various AISI and ASTM standards including ASTM C645, ASTM A653, ASTM C955, ASTM A1003, and AISI S200. Periodic inspections at our manufacturing locations by Home Innovation and testing at Home Innovation’s laboratory in Maryland verifies the product compliance. To maintain our Home Innovation certification, Super Stud is required to maintain a documented quality management system within strict guidelines, which is checked at each inspection.

Click Hereto see the current listing of certified facilities on the Home Innovation website.

Click Herefor our latest certification for our New Jersey manufacturing facility.

Click Herefor our latest certification for our Mississippi manufacturing facility.
